Product Details
Multi-face machining can be done with one clamping.2. The mechanical spindle can also automatically change the angle during the rotation.3. Can be divided into 3X120,4X90, 6X60, 8X45 and other conventional equal angles.4. Contains in-position detection signal to ensure safety when the index index is not in place.
Product Size
Product Parameters
| Model | Max.Clamping force kN(kgf) | Spindle hole (mm) | r.p.m (mm) | Weight kg | Matching cylinder | Max.pressure Mpa(kgf/cm²) | S(mm) | L(mm) | K(mm) |
| SGA-168 | 813 | >52 | 2800 | 16 | JR250 | 4.0(40) | 40 | 120 | 140 |
| SGA-185 | 813 | >52 | 3000 | 19 | JR250 | 4.0(40) | 45 | 140 | 145 |
| SGA-225 | 1270 | >52 | 2500 | 26 | JR250 | 4.0(40) | 65 | 160 | 165 |
| SGA-280 | 2550 | >60 | 2200 | 55 | JR500 | 4.0(41) | 80 | 220 | 250 |
| SGA-315 | 2550 | >60 | 1800 | 71 | JR500 | 4.0(42) | 110 | 250 | 260 |
| SGA-350 | 2550 | >60 | 1600 | 91 | JR500 | 4.0(43) | 135 | 280 | 270 |
| SGA-400 | 2550 | >60 | 1400 | 145 | JR500 | 4.0(44) | 170 | 320 | 2180 |
| Model | A | B | C(H6) | D | E | F | G | H | J | M | N | ST | R |
| SGA-168 | 168 | 140 | 140 | 178 | 5 | 72 | 30 | 68 | M10 | 34 | 38 | 9.5 | 104.8 |
| SGA-185 | 185 | 143 | 140 | 198 | 5 | 75 | 30 | 77 | M10 | 32 | 42 | 10.5 | 104.8 |
| SGA-225 | 225 | 154 | 170 | 225 | 5 | 84 | 35 | 95 | M12 | 46 | 58 | 11.5 | 133.4 |
| SGA-280 | 280 | 213 | 220 | 280 | 5 | 126 | 48 | 125 | M16 | 57 | 67 | 16.8 | 171.4 |
| SGA-315 | 315 | 232 | 220 | 315 | 5 | 136 | 50 | 136 | M16 | 76 | 85 | 19.4 | 171.4 |
| SGA-350 | 350 | 240 | 300 | 350 | 6 | 136 | 50 | 145 | M20 | 84 | 102 | 19.4 | 235 |
| SGA-400 | 400 | 259 | 300 | 400 | 6 | 140 | 60 | 165 | M20 | 100 | 114 | 30 | 235 |
-
